Samson SWXPD2HQ6 Handheld USB Digital Wireless System

ITEM DESCRIPTION

• 2.4GHz USB digital wireless system
• Ideal for broadcasting, live streaming, presentations and more
• Plug-and-play operation with Mac and Windows
• Works with iPad via Apple's Lightning to USB Camera Adapter
• Works with Android devices via a host OTG adapter
• RXD2 USB stick receiver
• Receiver features a 1/8" (3.5mm) headphone/monitor output
• HXD1 handheld microphone transmitter with Samson Q6 Dynamic Microphone element
• Transmitter offers 20 hours of battery life using two AA batteries (not included)
• 100' operating range (line of sight, environment dependent)
• 1-touch pairing, adjustable Volume controls on transmitter
• Compatible with Samson Expedition Series Portable PAs that feature USB Wireless ports
• Includes mic clip and USB extension cable

Specifications

XPD2 USB Digital Wireless System

• Simultaneous Systems: 2
• Working Range: 100' (30m) line of sight
• Working Frequency:  2.404~2.476GHz
• Modulation type: GFSK
• Audio Frequency Response: 20Hz–16KHz
• T.H.D.: <0.1% (@ 1KHz, -10dBu)
• Signal to Noise: >85dB

RXD2 USB Receiver

• Max. Analog Audio Output Level: 0dBu
• Audio Output Impedance: 100KΩ
• USB audio sample rate: 32KHz
• Operating Voltage: 5V DC
• Dimensions: 3.5" x 0.9" x .31" (89 mm x 23mm x 8mm)
• Weight: 0.35oz (10g)

HXD1 Handheld Transmitter

• Microphone Element: Q6 dynamic
• RF Power: <10 mW EIRP
• Power Requirements: Two AA (LR6) alkaline batteries
• Battery Life: 20 hours
• Dimensions: 10.2" x ø2.1" (260mm x ø54mm)
• Weight: 0.5lb (218g)
