Rockford Fosgate R2-750X5 5 Class D Amplifier
750W 5-Channel Full Range Class D Amplifier
Rockford Fosgate Prime R2-750X5 750W Prime Series 5-Channel Full Range Class D Amplifier
Primed for performance, the R2-750X5 is a 750 watt rated, full-range class-D amplifier capable of operating at 4Ω or 2Ω stereo with a mono subwoofer channel that can be run at 4Ω or 2Ω. The front/rear stereo channels can also be run at a 4Ω bridged/mono load. This amplifier is extremely efficient because of its Class-D technology which reduces demand on the vehicle's electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. supply that generates more dynamic power as voltage increases, and an integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass.
Rockford Fosgate's R2 amplifiers are the building blocks for great audio systems, powerful enough to even DRIVE our Punch speakers and subwoofers. They have undergone an amazing upgrade by packing them with the latest features at an incredible value. Best of all, they are designed and engineered here in Tempe, Arizona.
General Features:
- Rockford Fosgate Prime R2-750X2
- Class-D Full-Range 5-Channel Amplifier
- RMS Power Rating: 4 ohms: 50 watts x 4 Channel
- RMS Power Rating: 2 ohms: 100 watts x 4 Channel
- Bridged RMS Power Rating 4 ohms: 200 watts x 2 Channel
- Sub Channel: 4 ohms: 200 x 1 Channel
- Sub Channel: 2 ohms: 350 x 1 Channel
- Total power output: 600 watts
- Balanced Differential Inputs with RCA Pass Through Outputs
- High-Level Input Capable
- Defeat able Auto Turn on Circuit
- Features C.L.E.A.N. Set-up
- 2/4/5 Channel Input Selection Switch
- L.C. Remote Level Control
- Variable Infrasonic Filter
- Front, Rear, and Sub Variable Input Gain adjustment level
- Continuously Variable on-Board Punch EQ
- Top Mounted Control Panel
- Short Circuit & Over Current Protection
- CEA-2006 Compliant & CE Compliant
- Full Range Class D
- Rollback Protection
- Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
- Frequency Response: 20 Hz - 20 kHz
- Total Harmonic Distortion (THD): >1%
- Crossover Controls: Variable high-pass filter: 50 - 250 Hz, 24 dB/octave
- Crossover Controls: Variable low-pass filter: 50 - 250 Hz, 24 dB/octave
- Sub Low-Pass: 50 Hz - 250 Hz
- Sub Infrasonic: 15 Hz - 40 Hz
- Fuse Rating: 120A
- 4-gauge power and ground wiring are recommended for installation.
- Dimensions: 1.9"x6.8"x11.2"
- Authorized Internet Dealer
- 1-year Manufacturer's Warranty
What is in the box:
- 5-Channel amplifier
- Wired Remote Level Control module
- 16' Remote cable (RJ-25 connector on both ends)
- Three 7" Speaker input harnesses
- 3mm Allen Hex key
- Four 3/4" Screws
- Two 1/2" Screws
- 5 Flat washers
- 1 Nut
- Installation and Operation Instructions (English/ French/ Spanish/ German/ Italian)
- Certificate of Performance
- Rockford Fosgate contacts information
- Rockford Fosgate R2-750X5 owner's manual
