AUTOTEK MM1020.4 1000W Max (500W RMS) 4-Channel Class A/B Amplifier w/ Remote Level Control
- AUTOTEK MM1020.4 1000W Max (500W RMS) 4-Channel Class A/B Amplifier w/ Remote Level Control
-
Autotek Mean Machine MM1020.4
Class-A/B Full Range 4-Ohm Stable 4-Channel Amplifier
RMS Power Rating:
4 ohms: 125 watts x 4 chan.
2 ohms: 250 watts x 4 chan.
1 ohm: ------------N/A------------
Bridged, 4 ohms: 500 watts x 2 chan.
Total power output: 1000 watts
CEA-2006 Compliant Amplifier
Pulse Width Modulated MOSFET power supply
Wired remote bass level control included
LED power (green) and protect (red) indicators
Soft start turn-on
4/3/2 or Mono channel operation
Speaker-level (high-level) inputs
Preamp RCA outputs to daisy chain multiple amps
3-way protection circuitry (thermal, overload, and speaker short protection)
Dual speaker terminals simplify the hookup of multiple speakers
Heavy duty aluminum alloy heat-sink
Input sensitivity:
Low level: 125mV-5V
High level: 250mV-10V
Frequency Response: 30 - 12000 Hz
Total Harmonic Distortion (THD): <0.05%
Signal to Noise Ratio: >90 dB
Variable high-pass filter: 60 - 1200 Hz, 12 dB/octave
Variable low-pass filter: 30 - 250 Hz, 12 dB/octave
Variable Bass Boost: 0, +6, +12 dB bass boost at 50 Hz
Fuse Rating: 15 A x 2
4 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
