AudioControl The Epicenter Digital Bass Restoration Processor & Cerwin-Vega EQ-770 7-Band Graphic Equalizer Bundle + 2 Absolute RCA12 12' OFC Copper Rca Cable

Restore deep bass and fine-tune your entire audio system with this premium sound enhancement package featuring the AudioControl The Epicenter Digital Bass Restoration Processor and the Cerwin-Vega EQ-770 7-Band Graphic Equalizer. The Epicenter recreates low-frequency bass that is lost in compressed music and factory audio systems, while the EQ-770 provides precise 7-band equalization, subwoofer-level adjustment, an auxiliary input, and multiple high-voltage preamp outputs for complete system tuning.

General Features

• Complete Bass Restoration & Equalization Bundle

• Includes AudioControl The Epicenter Digital Bass Restoration Processor

• Includes Cerwin-Vega EQ-770 7-Band Graphic Equalizer

• Restores Lost Low Frequencies from Compressed Music

• 7-Band Audio Equalization

• Remote Bass Level Control Included

• Auxiliary Input for Additional Audio Sources

• Designed for Factory & Aftermarket Audio Systems

• Authorized Internet Dealer

• Manufacturer Warranty Included

AudioControl The Epicenter Digital Bass Restoration Processor

The AudioControl The Epicenter uses proprietary digital bass restoration technology to recover bass frequencies commonly removed during music compression and factory audio processing. It dramatically improves subwoofer performance while maintaining outstanding sound quality.

General Features

• 2-Channel Digital Bass Restoration Processor

• Bass Maximizer Circuitry

• Factory & Aftermarket System Compatible

• Speaker-Level Inputs

• Preamp Outputs

• Remote Bass/Gain Level Control Included

• Signal-Sensing Turn-On

• Multiple Turn-On Modes

• PFM Subsonic Filter Bypass

• Selectable Input Impedance (20Ω / 60Ω / 20kΩ)

Performance Specifications

• Frequency Response: 10Hz - 100kHz

• Signal-to-Noise Ratio: >130dB

• Total Harmonic Distortion (THD): 0.003%

• Subsonic Filter: 20Hz @ 12dB/Octave

• Fuse Rating: 1A

• Dimensions: 8-1/16" W x 1-1/4" H x 6-3/4" D

• Weight: 1.7 lbs

Cerwin-Vega EQ-770 7-Band Graphic Equalizer

The Cerwin-Vega EQ-770 provides complete control over your system's sound with seven adjustable EQ bands, independent subwoofer controls, and high-voltage preamp outputs for maximum signal quality.

General Features

• 7-Band Graphic Equalizer

• Auxiliary Input

• Red Illuminated Display

• Master Volume Control

• Independent Subwoofer Volume Control

• Adjustable Subwoofer Frequency Control

• Built-In Fader Control

• Three Sets of 7V Preamp Outputs (Front / Rear / Subwoofer)

• Nickel-Plated RCA Inputs

• Nickel-Plated Screw Terminals

Performance Specifications

• 7 Adjustable Equalizer Bands

• Signal-to-Noise Ratio: 90dB

• Frequency Response: 10Hz - 50kHz

• Channel Separation: 70dB

• Maximum Preamp Output: 7V

Package Includes

• (1) AudioControl The Epicenter Digital Bass Restoration Processor

• (1) Remote Dash-Mount Bass Control

• (1) Cerwin-Vega EQ-770 7-Band Graphic Equalizer

• Mounting Hardware

• Owner's Manuals

Installation Notes

• Compatible with most factory and aftermarket car audio systems.

• Install the Epicenter between the source unit and amplifier for optimal bass restoration.

• The EQ-770 provides complete system equalization and independent subwoofer level adjustment.

• Professional installation is recommended for best performance.
